APPC-8SF

Key Features

• 8-inch direct-bonded IPS touchscreen with non-glare coating
• Android 15 operating system with AI-ready NPU performance
• Rockchip RK3568 quad-core Cortex-A55 processor
• Power over Ethernet+ (PoE+) for simplified installation
• Surround LED Bar with full RGB control
• Integrated NFC reader (NXP PN7220)
• Radar motion sensor for proximity detection and touchless interaction
• 450 cd/m² high-brightness display for clear visibility
• Fanless design optimized for continuous 24/7 operation
• Integrated cable management for clean professional installations
• ProMGR cloud device management included (1-year subscription)
• Direct-bonded display for improved touch accuracy and reduced parallax
• VESA 75 mounting compatibility

Specification

The ProDVX APPC-8SF is a professional Android panel PC designed for modern workplace environments such as meeting room booking systems, building management panels, digital signage, and control interfaces. With its compact 8-inch form factor and slim bezel design, the device integrates seamlessly into offices, conference rooms, hospitality environments, and smart building infrastructures.

Powered by the Rockchip RK3568 quad-core Cortex-A55 processor, the panel delivers reliable performance for enterprise applications while maintaining energy efficiency. The system includes 4 GB LPDDR4 RAM and 16 GB eMMC storage, ensuring smooth operation of room booking software, dashboards, and custom business applications.

The direct-bonded IPS display significantly improves touch accuracy and visual clarity while minimizing glare and parallax. Combined with 450 cd/m² brightness, the screen remains easily readable even in brightly lit environments. The device also includes AI-ready NPU capabilities, allowing local AI processing without external hardware.

Designed specifically for professional deployments, the APPC-8SF supports Power over Ethernet+, enabling both power and network connectivity through a single cable. This simplifies installation and reduces infrastructure complexity. The housing includes concealed I/O ports and integrated cable routing to ensure clean wall-mounted installations.

Additional hardware features such as the Surround LED Bar, integrated NFC reader, and radar motion sensor allow advanced interactions like presence detection, access control integration, or dynamic room status visualization.

Built with reliability in mind, the device features a fanless cooling design, industrial-grade components, and is engineered for 24/7 continuous operation. Combined with ProDVX platform services such as ProMGR remote device management and ProSECURE security framework, the APPC-8SF provides a stable and scalable solution for enterprise device deployments.
