Elo 10 inch I-Series 5, with 2 x LED Strips
Elo 10 inch I-Series 5, with 2 x LED Strips
Elo Touch Solutions, Inc.
Regular price
€811,00
Regular price
Sale price
€811,00
Quantity
Only for B2B customers!
Couldn't load pickup availability
10" I-Series 5 with Android
- 10-point PCAP touch display
- Android 14 with Google Mobile Services
- Modular Edge Connect RGB status light (extension)
- Qualcomm QCS6490 processor
- Wi-Fi 6E + Bluetooth 5.2
- PoE capable
- Ideal for meeting room signage & smart office devices
| SKU | Name |
| E539154 | ELO 10,1" I-Series 5, P-Cap, A_14, BLACK |
| E644767 | ELO Edge Connect Status LED - BLACK |
| E644767 | ELO Edge Connect Status LED - BLACK |
Additionally, we recommend buying the following not included article:
E143088 - Wall Mount
E669163 - ELO PoE-Modul (für I-Serie 4 und 5)
E898282 - ELO Android EloCare OS360, 5 years
Specification
Elo’s 10″ I-Series 5 combined with the Edge Connect Status Light delivers a compact, enterprise-grade Android touch system with real-time room status indication. Built on the Qualcomm QCS6490 platform with Android 14, it offers fast performance, high display clarity, and modular accessory support through the Edge Connect interface—perfect for meeting rooms, door signage, and interactive workspace applications.
| Part Number(s) | E539154 |
| Enclosure Color | Black |
| Touch Technology | PCAP (10-touch) |
| Processor | Qualcomm Snapdragon QCS6490 |
| Memory (RAM) | 8 GB |
| Storage | 64 GB |
| Operating System | Android 14 with GMS OS 360 upgrade path to Android 16 & 18 |
| Diagonal Size | 10.1″ TFT LCD |
| Resolution | 1920 x 1200 |
| Brightness | 400 nits (typical) |
| Contrast Ratio | 800:1 |
| Wireless | Wi-Fi 6E, Bluetooth 5.2 |
| Connectivity | USB-C, USB-A, LAN, GPIO, Edge Connect ports |
| Status Light | RGB LED indicator (Edge Connect) Programmable via SDK |
| Speakers | 2x 2W |
| Mounting Options | VESA 75 mm |
| Power | AC or optional PoE |
| Dimensions | Approx. 10.1″ class chassis |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 50°C |
| Humidity | Operating: 20%–80% |
| Regulatory Approvals | UL, FCC, CE, IC, RCM, etc. |
| Warranty | 2-year standard |
