ProDVX APPC 10SFN (R25-7281)
ProDVX APPC 10SFN (R25-7281)
ProDVX Europe BV
Only for B2B customers!
Couldn't load pickup availability
APPC 10SFN
- 10.1" Panel PC
- Android 13 AOSP
- Direct Bonded Display
- Status LED Bar, Integrated NFC
- without in-built accumulator
- Connection options
- PoE (Power over Ethernet)
- Ethernet + USB-C Power
- (optional with dongle) WiFi + USB-C Power
Hardware Guarantee
There is a 3-year standard hardware guarantee by the manufacturer by default for the APPC 10SFN. Optionally, the guarantee can be extended from 3 years to 5 years by purchasing the ProSurance option (base price + 25%).
Software Updates
The current version of the APPC 10SFN Display is the Android 13 AOSP, which is by default supported by Google with security updates until the end of 2026. After the official Google Support, ProDVX is providing security updates for the Android 13 AOSP version until the end of 2029.
Until the end of 2026, there will be an OS update for the 10SFN displays from Android 13 AOSP to Android 15 AOSP. The already acquired APPC 10SFN displays can be updated to Android 15 then, which has official Google Support until the end of 2028 and will receive additional security updates from ProDVX until the end of 2031.
Other Android versions may be available down the line. These are the currently announced versions and dates that we know of. The providers, such as ProDVX and Google, may change the dates; therefore, we are not liable for the communicated software update information.
Product Specification
The ProDVX APPC-10SFN is a versatile 10.1” Android Panel PC featuring a full surround LED bar and an integrated NFC reader, making it perfect for dynamic environments and interactive applications. Powered by the RockChip RK3568 quad-core processor and running Android 13, it delivers reliable performance with 4 GB RAM and 16 GB storage, expandable via SD card. The customizable Full Surround LED bar enhances branding or provides visual status indicators, while the NFC reader (NXP PN7160) enables seamless contactless interactions, ideal for retail, hospitality, and access control. Its direct-bonded IPS touchscreen with 1280 x 800 resolution offers sharp visuals and responsive touch, complemented by PoE+, fanless cooling, mini-HDMI out, and versatile connectivity options (USB, LAN). Designed for 24/7 operation with a demonstrated MTBF of 50,000 hours, this compact yet durable device supports flexible mounting options to meet diverse business needs.
Panel
| Panel type | Direct bonded TFT LCD IPS |
| Resolution | 1280 x 800 |
| Backlight | Edge-LED backlight |
| Brightness | 450 cd/m2 |
| Viewing angle | H160 / V160 |
| Contrast ratio | 1000 to 1 |
| Touch Type | 10 TP Pcap 10ms |
| Treatment | Non-glare |
| Convenience | Landscape,Portrait,Flushmount |
| Operation hours | 24h / 7d |
System
| GPU | Mali-G52 |
| Cooling | Fanless |
| Video input | N.A. |
| Video out | Yes, mini-HDMI out |
| External storage | SD-Card Slot |
| OS | Android 13 |
| LED Light Bar | Individually controlled Full RGB LED |
| Network LAN RJ45 | 10/100/1000 Mbps LAN |
| WiFi | optional via USB dongle |
| Bluetooth | optional via USB dongle |
| Power over Ethernet (PoE) | IEEE 802.3at (PoE+) |
| Integrated NFC | Integrated NFC reader (NXP PN7160) |
| Camera | via PoGo & USB |
Video / Audio
| Video support | H.264,MP4,MPG,MPEG2,MPEG4 |
| Audio support | AAC,ASF,MP2,OGG,WAV,WMA |
| Photo support | JPG,JPEG,PNG,BMP,GIF |
| Microphone | Yes |
| Speakers | 2 x 2 W |
Physical
| Housing | ABS+PC (Macrolon) |
| Color | Black |
| Weight | 600 g |
| Dimensions | 240,9 x 159,7 x 24,4 mm |
| Mounting / VESA | VESA 75 |
| Power Supply | 12 V / 2 A (EU, UK, US) |
| Power Usage | 10 ~ 23 Watt |
| Pogo Pins | 2x (bottom/left) |
Other
| OSD Language | Multi OSD language |
| Clock Battery (for RTC) | CR1220 Lithium metal, non rechargeable |
| Storage Temp | -10~55 degrees C |
| Working Temp | 0 ~ 40 degrees C |
| Storage/Working Humidity | 10 ~ 90 % non-condensing |
| MTBF | 50,000 hours demonstrated |
| Standard Warranty | 3 years |
| Certifications | UKCA, CE, FCC, RoHS, REACH |
| SKU | 5010730 |
